INVEREX NITROX 6 KW SINGLE

7.4
Expert ScoreRead review
  • Volts: 48V
  • Transfer Time: 4 Ms
  • Cooling: Smart Cooling
  • Noise: 30 db
  • Phase: Single Phas

Original price was: ₨ 439,999.Current price is: ₨ 434,999.

Added to wishlistRemoved from wishlist 1
Add to compare

Inverex Nitrox 6 KW Single Phase Hybrid Solar Inverter Price in Pakistan IS PKR 439,999.

Inverex Nitrox 6KW Single Pahse Hybrid Solar Inverter Price in Pakistan is 439,999/. This company is one of the leading solar companies in Pakistan. They provide a lot range of customized integrated solar solutions and home products to different sectors. The manufacturing and suppling plant is in China. Mr. Zakir Ali is the owner of Inverex. The Inverex Invertor provide the power to various appliances in home or office environment. Including motor type appliances such as Air conditioner, refrigerator, light, fan etc. This model has a lot features like compatible with Inverex cable. External light indicator, no external power needed, easy to plant etc. It comes in 330W x 433H x 238D size, with 48 volts. 4ms transfer time, IP 65 protection degree. Single phase type, <30 db noise, 14Kg weight hybrid solar inverter.

inverex-nitrox-8kw-hybrid-solar-inverter-Price in Pakistan

Specification:
  • Volts:  48V
  • Transfer Time:  4 Ms
  • Cooling:  Smart Cooling
  • Noise:  30 db
  • Phase:  Single Phase
  • Type:   Hybrid Solar Inverter
  • Weight:  14Kg



Specifications:

Model Number:    Nitrox Hybrid 6KW SP-48V


Battery

Type:                                             Lead-Acid or Lithium-ion

Volt Range (V):                               40-60

Max. Charging Current:                135

Max. Discharging current:              135

External Temperature Sensor:        Optional

Charging Curves:                             3stages/ equalization

Charging Strategy for Lio-ion battery:     Self adaption to BMS



PV string input data

Max. DC input power (W):                            7800W

Rated PV input voltage (V):                           370(125-500)

Startup voltage (V):                                        125

MPPT Voltage Range (V):                             150-425

Full loaded DC voltage:                                  300-425

PV input current (A):                                      13+13A

Max. PV ISC(A):                                              17+17A

Number of MPPT/String per MPPT:              2/1+1





AC Output Data

Rated AC Output and UPS Power (W):                                 6000

Max. AC output power(W):                                                   6600

AC output Rated Current(A):                                                 27.3/26.1A

Max. AC current (A):                                                             30/28.7A

Max Continues AC passthrough (A):                                     40

Peak Power (off-grid):                                                            2 time of rated power, 10S

Power Factor:                                                                          0.8 leading to 0.8 lagging

Output frequency and voltage:                       50/60Hz; 220V/187V-242V,230V/195.5-253V

Grid Type:                                                                              Single Phase

DC injection current (mA):                                                     THD<3% (liner load<1.5%)



Frequency

Max. Efficiency:                                                                     97.60%

Euro Efficiency:                                                                      96.50%

MPPT Efficiency:                                                                   >99%

Transfer Time:                                                                         4ms



Protection:

Integrated:                                                                   PV Arc Fault Detection, PV input lightning protection, Anti-                                                                                        Islanding protection, PV string input reverse polarity                                                                                                    protection, Insulation resistor detection, Residual current                                                                                            monitoring Unit, output over current protection, output                                                                                              shorted protection,



General Data

Operation Temperature Range (◦C):                                       -40-60◦C, >45◦C derating

Cooling;                                                                                  Smart cooling

Noise (dB):                                                                                         <30dB

Communication with BMS:                                                                RS485; CAN

Weight (Kg):                                                                                       14

Size (mm):                                                                                          330W x 433H x 238D

Protection Degree:                                                                              IP65

Installation Style:                                                                                Wall Mounted

Warranty:                                                                                            5 years (T&C)



Check out more Inverex solar inverters.

Happy Shopping with Costyo.pk

Specification: INVEREX NITROX 6 KW SINGLE

Solar Inverter Brands

Inverex

Solar Inverter Sizes

6KW

Solar Inverter Types

Hybrid Inverter
